Module specification
MaterialSTS 316, Electropolishing and acid treatment
Lamp type / input powerLP UV Lamp
Cleaning SystemElectric Motor-driven Automatic Wiper Mechanism
Operating Temperature5℃~65℃
ConnectionP16, DN, ANSI150, JIS, KS
Working / Max Operating Pressure10bar / 15bar
Enclosure Specification
MaterialRAL 7032, Mild steel (Optional StSt 304 available)
Protection RatingIP54 / NEMA 4X
System Control Panel (SCP)
Voltage / Frequency220V~480V / 50/60Hz
Operating Temperature0℃~50℃
Power Supply Panel (PSP)
Ballast typeVariable output electronic ballast
Cost Efficiency· Lower total cost compared to the initial investment
Maintainability· Simplified facilities and integrated automation make it easy to maintainability
· Combined operation possible
- Normal Sterilization: Remove substances that are difficult to remove with chlorine
- Micro, new contaminants detected: UV + Oxidation(H2O2 ), etc
